Rapid-build martial arts hall
A martial arts hall is designed around the specific discipline: clear height, cushioned flooring, impact-protective wall finishes, diffuse lighting and supply-and-extract ventilation sized for the number of participants. Changing rooms with showers, coaching rooms and plant rooms are part of the scope.
What the modular solution delivers
- 01 Full compliance with safety codes
- 02 Универсальность: адаптация под разные виды единоборств
- 03 30–40% lower capital cost
- 04 Relocatable: can be dismantled and moved
- 05 Turnkey delivery in 2–3 months
- 06 Considered layouts and daylighting
- 07 Comfortable operating conditions
The building arrives with services installed
Engineering systems are installed at the plant; on site only the connection to external networks remains.
- Water supply
- Sewerage
- Heating
- Ventilation
- Power supply
- Fire suppression
- Security and low-voltage systems
Scope and specification
01 Technical specification
- Floor area
- 200–500 m²
- Ceiling height
- 4.5–6 m
- Load-bearing structure
- steel frame
- Floor covering
- specialist sports flooring
- Lighting
- professional sports lighting
02 Layout
- Main training space
- Tatami or ring, Warm-up areas, Striking practice areas
- Ancillary rooms
- Changing rooms with showers, Washrooms, Coaching rooms, First-aid room
- Administrative section
- Management offices, Teaching resource room, Staff lounge
03 Design features
- Building frame
- Steel profiles with anti-corrosion coating, Quick-release connections, Modular expansion capability
- External walls
- Sandwich panels with enhanced sound insulation, Energy-efficient materials
- Interior finishes
- Moisture-resistant materials, Anti-vandal coatings, Fire-safe materials
04 Engineering systems
- Ventilation
- Supply and extract system, Air filtration, Humidity control
- Heating
- Standalone system, Adjustable temperature settings
- Power supply
- Primary and emergency lighting, Sockets for sports equipment
05 Advantages of the solution
- Installation speed
- 2–3 months, turnkey
- Mobility
- can be dismantled and relocated
- Cost efficiency
- 30–40% cost reduction
- Versatility
- adaptation to different martial arts
- Safety
- compliance with all standards
06 Additional equipment
- Sports equipment
- Tatami, Ring or octagon, Punch bags, Striking equipment
- Security systems
- CCTV, Fire alarm, Access control system
